ULTRASONIC CLEANERS AND ULTRASONIC EXPLOSION PROOF BLIND CLEANERS AND CLEANING ACCESSORIES - HIGH POWER, INDUSTRIAL STRENGTH ULTRASONICS

Electrowave Ultrasonics Corporation
 PHONE: (858) 695-2227          FAX: (760) 751-4081
Ultrasonic Cleaners
Most Powerful Ultrasonics In The World
....and we're not kidding! - Direct from factory
Manufacturers of the finest built, most powerful ultrasonic cleaning equipment in the world. As manufacturing requirements for cleanliness become ever more stringent, the ultrasonic cleaning equipment ELECTROWAVE provides has risen to the top to become the "de facto" standard in the industry. Our clients include businesses large and small, governments, military and multinationals around the globe. These units utilize an extremely efficient ceramic transducer system like no other ultrasonic manufacturer. This specialized transducer system produces a substantially higher movement to millivolt response (D33), more than anything seen in this industry! The power of our ELECTROWAVE transducers will produce cavitation in the force range of over one hundred thousand psi! Our product will easily meet your most demanding requirements and out-perform any other brand on the market. No other ultrasonic manufacturer can offer you more power at any price. Guaranteed cavitational intensity in all units greater than 750 micro amperes per square centimeter, units can be produced with up to 100,000 watts of cleaning power, and at frequencies automatically fine tuned (13KHz - 100KHz) for load variations. Heavy-duty transducers utilizing piezo-electric elements for the highest efficiency. All stainless steel construction for long life.

 Electrowave Table Top Units

 Model



Inside Tank Dimensions

L" X W" X D"

 Peak Watts*



Capacity

With Timer Price

With Timer & Heater Price

Gallons

Liters

EW-3

9.5 x 5.5 x 4

 360

0.9

3.4

$ 300.00

$ 350.00

EW-6

12 x 6.25 x 6

 435

1.9

7.2

$ 485.00

$ 550.00

EW-11

 12 x 9.5 x 6

750

2.9

11

$ 695.00

$ 795.00

EW-12

12 x 9.5 x 8

750

 3.9

14.8

$ 795.00

$ 895.00

EW-13

20 x 6 x 6

 750

 3.1

11.7

$ 795.00

$  895.00

EW-14

13 x 12 x 6

 795

4.0

15

$ 925.00

$ 1050.00

EW-21

20 x 12 x 6

1045

6.2

23.5

$ 1250.00

$ 1425.00

EW-22

20 x 12 x 8

1045

 8.3

31.4

$ 1400.00

$ 1575.00

EW-24

24 x 8 x 6

 1010

 5.0

18.9

$ 1275.00

$ 1450.00

EW-30

30 x 8 x 6

1010

6.2

23.5

$ 1425.00

$ 1600.00

 EW-36

36 x 8 x 6

 1310

7.5

28.4

$ 1700.00

$ 1875.00

EW-40

40 x 8 x 6

1310

8.3

31.4

$ 1850.00

$ 2050.00

Tank Covers and Perforated Baskets
Stainless Steel Cabinets: Standard on all units.
Piezo-Electric Transducers
Power Requirements: Standard 120 VAC 50/60 Hz.  See Separate Price Schedule for 220 VAC.
Timer: Can be set for up to 30 minutes.
Frequencies: Available in 40 kHz to 60 kHz.
Heat Option: Factory preset maximum 140 degrees Fahrenheit.
Drain: Standard on model EW-12 and larger - for smaller models add $25.00.
Explosion Proof Ultrasonic Cleaners: N.E.C., N.F.P.A., & O.S.H.A. Explosion proof extra for models EW-3 to EW-6 add $500, models EW-11 to EW-14 add $750, and models EW-21 to EW-40 add $1000.
CABINET - SU model (Self Contained) Series Data Sheet
SEPARATE - ES model (Remote Generator) Series

 Model

Inside Tank
Dimensions
 L" X W" X D"

 Average Watts*

 Capacity in Gallons

 With Timer Price

 With Timer & Heater Price

 60

14 x 12 x 10

500

7

$ 2235.00

$ 2575.00

100

14 x 14 x 12

750

10

$ 2695.00

$ 2995.00

110

18 x 14 x 10

1000

11

$ 3025.00

$ 3350.00

160

20 x 16 x 12

1500

17

$ 4080.00

$ 4570.00

180

24 x 18 x 10

1700

19

$ 4455.00

$ 4995.00

250

24 x 24 x 10

2000

25

$ 5400.00

$ 6090.00

400

24 x 24 x 16

3000

40

$ 8425.00

$ 8795.00

425

36 x 22 x 18

4000

62

$ 14575.00

$ 16850.00
 900 36 x 24 x 24 5000 90 $ 19350.00

$ 22750.00

Tank Covers and Perforated Baskets
Stainless Steel Cabinets: Standard on all units.
Langevin Bolt Transducers
Power Requirements:
Models 60 to 180 made for 120 VAC 50/60 Hz operation.
Models 250 to 400 made for 220 VAC 50/60 Hz, Single Phase operation.
Models 425 to 900 made for 220 VAC 50/60 Hz. Three Phase operation.
Timer: Can be set for up to 30 minutes.
Separate Generator: 15’ cable - ES Series add $250.00.
Casters: 5" - add $250.00.
Explosion Proof Ultrasonic Cleaners: ES and SU models - Inquire.
Frequencies: Available in 13KHz to 100KHz.
Heat Option: Factory preset maximum 140 degrees Fahrenheit.
Variable Heat Control: Ambient to 200 degrees Fahrenheit add $250.00.
Variable Intensity Control: Add $250.00 for models 60 to 160, $350.00 models 180 to 250, inquire for larger.
Magnetostrictive Systems available. Call for quote.
Custom Systems or for conformance to any particular military or FAR specifications consult factory.
PROFESSIONAL BLIND CLEANERS
More Information On Blind Cleaners
Model
Tank Inside Dimensions
L" x W" x D"

Overall
Dimensions
L" x W" x D"
Price
With Timer
Price
With Timer and Heater
 500
63x12x18
67x19x38
$ 7995.00
$ 8495.00
 600
75x12x18
79x19x38
$ 8995.00
$ 9595.00
 700
87x12x18
91x19x38
$ 9995.00
$ 10695.00
 800
99x12x18
103x19x38
$ 10995.00
$ 11795.00
 900
111x12x18
115x19x38
$ 11995.00
$ 12895.00
 1000
123x12x18
127x19x38
$ 12995.00
$ 13995.00


Utilizes ELECTROWAVE Langevin Bolt (Vibra-Bar) Transducers. Locking casters, Timer, Intensity and Heat Control Switching are all Standard. Our blind cleaners are built to the strictest of industrial standards.
Also Available
Agitating Parts washer
Cavitation meters
Chemicals
Custom Units
Explosion-Proof Ultrasonics
Laboratory hot water baths
Specialty research apparatus
Steam cleaning equipment
Vapor degreasers
Submersible Ultrasonic Systems

Call for specifications, pricing and delivery
